Treatment Units of CETP :-
Old module of 2.15 MLD
- Bar Screen/Grit Chamber:-1no.-Manual MOC-RCC/M20
- Equalisation cum Holding system:-2 no. MOC-RCC/M20 width coarse Bubble Diffusers as equalization device
- Open to Sky Type Pump House:-1no. Effluent Pumps-Battery of Pumps (Helical Non-Clog) MOC-RCC/M20
- Flash Mixer:-1no. MOC-RCC/M20 Flash Mixing agitator-SS316-1no.
- Clariflocculation System:-1 no. Device-Flocculation Paddles-MS-Epoxy coated Peripherial Clarifier.
- Ist Stage Conventional Aeration System:- 1 no. MOC/RCC-M20-Fixed Surface Aerators-Low speed Type,20HP-4 nos.
- IInd Stage Extended Aeration System:- 1 no. MOC/RCC-M20-Fixed Surface Aerators-Low speed Type,10HP-4 nos.
- Ist Stage Clarifier (Biological):- 1no. MOC/RCC-M20 Device-Peripherally driven clarifier with central shell.
- IInd Stage (Biological) Clarifier:- 1 no. MOC/RCC-M20 Device-Peripherally driven clarifier with central shell.
- Tertiary Clarifier :- 1 no. , fitted with NGF and ACF.
- Final discharge trough/V-Notch arrangement:- 1 set MOC/RCC-M20. Launder connected to RCC-NP3 pipe connecting finally to UPSIDC’s Pucca Drain receiving the treated effluent from CETP.
New upgraded module of 2.35 MLD CETP installed and commissioned as per direction of UPTCC and sanctioned under IIUS of Government of India, DIPP Ministry of commerce & industry, New Delhi
This new module received the treated effluent from above old module and treats its finally through extended aeration system to achieve constant quality of trated effluent with in the prescribed standard of UPTCC Lucknow.
- Bar Screen/Grit Chamber:-1no.-Manual MOC-RCC/M20
- Equalisation cum Holding system:- 4 no. MOC-RCC/M20 /BW width fine Bubble Diffusers as equalization device.
- Open to Sky Type Pump House:-4 no. Effluent Pumps-Battery of Pumps (Helical Non-Clog) MOC-RCC/M20
- Flash Mixer:-1no. MOC-RCC/M20 Flash Mixing agitator-SS316-1no.
- Clariflocculation System:-1 no. Device-Flocculation Paddles-MS-Epoxy coated Peripherial Clarifier.
- Ist Stage Conventional Aeration System:- 1 no. MOC/RCC-M20-Fixed Surface Aerators-Low speed Type,25HP-4 nos.
- IInd Stage Extended Aeration System:- 1 no. MOC/RCC-M20-Fixed Surface Aerators-Low speed Type,15HP-4 nos.
- Ist Stage Clarifier (Biological):- 1no. MOC/RCC-M20 Device-Peripherally driven clarifier with central shell.
- IInd Stage (Biological) Clarifier:- 1 no. MOC/RCC-M20 Device-Peripherally driven clarifier with central shell.
- Tertiary Clarifier :- 1 no. , fitted with NGF and ACF.
- Final discharge trough/V-Notch arrangement:- 1 set MOC/RCC-M20. Launder connected to RCC-NP3 pipe connecting finally to UPSIDC’s Pucca Drain receiving the treated effluent from CETP.
Pollution Reduction Strip :- stage - wise performance of new module of CETP
- Physio-chemical - 30-40%
- Ist stage Biological treatment system - 60-65% treatment of remaining BOD/COD
- IInd stage Biological Treatment - 95-96% reduction of remaining BOD/COD
- Tertiary Treatment stage - Polishing
- Expected Quality of treated effluent - >PH=7-7.5, BOD=10-15mg/l, COD=150-240, mg/lSS=10-50mg/l
- UPPCB Norms Status - PH=6.0-9.0, BOD<30mg/l, COD < 250mg/l, SS<100mg/l
Power requirement :-
350 KVA.
Temporary solid waste storage facility inside the CETP
Existing for about 3 months capacity
